inup Frameless Infrared Heater – Square

inup Frameless Infrared Heater – Square

Reduction at its most refined. Heat that steps back – yet delivers everything.

The Frameless Square series embodies inup’s principle of uncompromising clarity: frameless, minimalist, technically perfected. Made from premium industrial glass-ceramic, this infrared heater offers not only visual precision – but deeply felt warmth.

Thanks to a screwless spring-mount system, the unit blends seamlessly into wall or ceiling. Its sun-like full-spectrum ABC radiation delivers consistent deep heat – with exceptionally long-lasting performance. A radiant force that works – and endures.

Recommended Use. Refined in Every Detail.

Frameless Square infrared heaters come in four power levels – precisely matched to different body zones and use cases:

• 350 W: For back or lower legs – ideal distance: 10–20 cm

• 500 W: Especially effective for the back – 30–50 cm

• 750 W: Perfect for front-facing use – 60–80 cm

• 1300 W: Designed for ceiling mounting – 90–110 cm

This ensures the warmth not only reaches you – but works exactly where it’s needed.

Highlights

• Frameless square design with clean visual lines

• High-grade glass-ceramic surface with pleasant light diffusion

• Invisible spring-mounted installation – no screws, no compromises

• Full-spectrum infrared (A-23%, B-57%, C-20%) for natural deep heat

• Matte black aluminium casing – compact and elegant

• 10,000-hour lifespan

Technology & Dimensions

Power levels:
• Wall-mounted: 350 W / 500 W / 750 W
• Ceiling-mounted: 1300 W

Dimensions (H×W×D):
• 750 × 180 × 42 mm (Wall)
• 750 × 180 × 68 mm (Ceiling, 1300 W)
• Cut-out size: 715 × 148 mm

Details:
• Connection: 230 V | 50 Hz | 3×1.5 mm² silicone cable, 3 m (no plug)
• Light output: 150 lumens
• Protection rating: IPx4

Included in Delivery

• 1× Frameless Square Infrared Heater

• 1× 3 m silicone connection cable

• 1× Technical instruction manual
